Feature
- Longer Life at lower cost
- High adhesion
- Cut edge construction
- Excellent efficiency of Vulcanized splice
- Complete efficiency of vulcanized splice.
- Proper loading support
- Highest resistance to mildewed moisture.
- Highest resistance to impacted material trapping
Cover Rubber for General purpose
| Standard |
Grade |
Tensile Strength |
Tensile strength (kgf/cm2) |
| CNS |
S |
18 Mpa |
180 |
| JIS |
S |
18 Mpa |
180 |
| RMA |
RMA I |
2500 psi |
180 |
| RMA II |
2000 psi |
140 |
| BS |
N17 |
17 Mpa |
180 |
| M24 |
24 Mpa |
240 |
| DIN |
W |
18 N/mm2 |
180 |
| X |
25 N/mm2 |
240 |
| Y |
20 N/mm2 |
180 |
| Z |
15 N/mm2 |
150 |
| ISO |
H |
24 N/mm2 |
240 |
| D |
18 N/mm2 |
180 |
| L |
15 N/mm2 |
150 |
| AS |
N |
18 Mpa |
180 |
| M |
24 Mpa |
240 |
Tensile strength and number of ply
| Strength |
2 ply |
3 ply |
4 ply |
5 ply |
6 ply |
| 160 |
160/2 |
|
|
|
|
| 200 |
200/2 |
|
|
|
|
| 250 |
250/2 |
250/3 |
|
|
|
| 315 |
315/2 |
315/3 |
|
|
|
| 400 |
400/2 |
400/3 |
400/4 |
|
|
| 500 |
|
500/3 |
500/4 |
500/5 |
|
| 630 |
|
630/3 |
630/4 |
630/5 |
630/6 |
| 800 |
|
800/3 |
800/4 |
800/5 |
800/6 |
| 1000 |
|
1000/3 |
1000/4 |
1000/5 |
1000/6 |
| 1250 |
|
|
1250/4 |
1250/5 |
1250/6 |
| 1500 |
|
|
|
1500/5 |
1500/6 |
| 1600 |
|
|
|
1600/5 |
1600/6 |
| 1800 |
|
|
|
|
1800/6 |
| 2000 |
|
|
|
|
2000/6 |
HSING KWO RUBBER MFG. CO., LTD
Regular Specification List of Multi-Ply Conveyor Belt
| ITEM NO. |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
| Number of Plies |
2 |
3 |
2 |
2 |
2 |
2 |
3 |
3 |
4 |
4 |
2 |
3 |
| Tension Rating (PIW) |
150 |
225 |
150 |
150 |
220 |
220 |
330 |
330 |
440 |
440 |
220 |
330 |
| Top Cover Thickness (inch) |
BARE |
BARE |
1/32” |
1/32” |
1/8” |
3/16” |
3/16” |
1/4" |
1/4" |
3/8” |
3/16” |
3/16” |
| Bottom Cover Thickness (inch) |
BARE |
BARE |
BARE |
1/32” |
1/16” |
1/16” |
1/16” |
1/16” |
1/16” |
3/32” |
1/16” |
1/16” |
| Overall Gauge (mm) |
2.8 |
3.6 |
3.9 |
4.2 |
7.5 |
9.0 |
10.2 |
11.8 |
13.4 |
17.2 |
9.0 |
10.2 |
| Color |
- |
- |
Black |
Black |
Black |
Black |
Black |
Black |
Black |
Black |
Black |
Black |
| Rubber Grade |
RMA II |
RMA II |
RMA II |
RMA II |
RMA I & II |
RMA I & II |
RMA I & II |
RMA I & II |
RMA I & II |
RMA I & II |
400°F |
400°F |
| Available Widths (inch) |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
Max. 80” |
| ITEM NO. |
13 |
14 |
15 |
16 |
17 |
18 |
19 |
20 |
21 |
22 |
23 |
| Number of Plies |
3 |
2 |
3 |
2 |
3 |
3 |
2 |
3 |
3 |
2 |
3 |
| Tension Rating (PIW) |
330 |
220 |
330 |
150 |
225 |
225 |
220 |
330 |
330 |
220 |
330 |
| Top Cover Thickness (inch) |
1/4” |
3/16” |
3/16” |
R.T. |
R.T. |
R.T. |
1/8” V6 Cleat |
1/8” V6 Cleat |
1/8” V6 Cleat |
1/8” Chevron |
3/16” Chevron |
| Bottom Cover Thickness (inch) |
1/16” |
1/16” |
1/16” |
BARE |
BARE |
BARE |
1/16” |
1/16” |
BARE |
1/16” |
1/16” |
| Overall Gauge (mm) |
11.8 |
9.0 |
10.2 |
6.7 |
7.5 |
7.5 |
12.1 |
13.7 |
12.1 |
- |
- |
| Color |
Black |
Black |
Black |
Black, Tan |
Black, Tan |
Pure Gum |
Black |
Black |
Black |
Black |
Black |
| Rubber Grade |
400°F |
300°F |
300°F |
- |
- |
- |
MOR |
MOR |
MOR |
MOR |
MOR |
| Available Widths (inch) |
Max. 80” |
Max. 80” |
Max. 80” |
48” & 60” |
48” & 60” |
48” & 60” |
60” |
60” |
60” |
40” Below |
40” Below |
* Other specifications are also available, please contact our sales office for further information.
